Multi-sliding-GL-105-2L2R

System Overview:
The GL-105-2L2R is a Slim Frame multi sliding façade designed to open wide architectural spaces seamlessly, providing panoramic views with minimal visual interruption. The system allows all panels to slide smoothly to both sides without the need for a bottom track, ensuring a clean and modern architectural appearance and a full visual connection between indoor and outdoor spaces.

Engineering Configuration:
The system is manufactured using high-quality aluminum profiles with a Slim Frame design and operates with a multi-track sliding mechanism supported by a fully top-hung load system, ensuring balanced load distribution and stable panel movement.
The façade consists of four fully movable panels arranged as two panels on the right side and two panels on the left side, with no fixed panels, allowing complete flexibility for partial or full opening based on usage requirements.
The system is fitted with single glazing, providing lightweight operation and clear visibility while maintaining reliable performance.
All movement tracks are integrated within the upper aluminum profile, utilizing two internal top tracks designed to ensure smooth and controlled panel movement according to site dimensions and layout.
No bottom track is used. Each panel is supported by circular guide wheels beneath the panel that function solely as guiding and stabilizing elements, ensuring precise alignment and smooth sliding without any load-bearing function.
The system offers full flexibility in customizing the glass type, number of panels, number of tracks, profile heights, and handle positions, in accordance with client requirements and site conditions, while maintaining approved structural performance, smooth operation, and safety standards.

Accessories:
All accessories are manufactured entirely from high-quality aluminum and include a soft-close system for smooth and quiet operation, integrated recessed handles within the panel thickness, and full-height sealing brushes between panels.
All hardware is fully concealed within the profiles to maintain a clean and refined architectural appearance.

Safety and Insulation:
The façade is equipped with rubber gaskets between the glass and aluminum profiles, along with full sealing between panels to prevent dust and insect infiltration. The system ensures secure locking and safe, smooth operation even with frequent daily use.

Optional Folding Aluminum Mesh System:
The façade can be equipped with an optional folding aluminum mesh system featuring fine ventilation openings, perimeter brush sealing, and a central locking mechanism (ON/OFF). This allows natural ventilation while preventing insects and maintaining privacy.

Areas of Use:
Villas with wide openings
Restaurants and cafés
Commercial spaces

Maintenance and After-Sales Service:
The system features easy maintenance with readily available spare parts, supported by professional technical support and after-sales service backed by Green Line’s experience in large-scale projects. The system includes a paint warranty of up to 25 years only.
