Hybrid Multi-Sliding & Hinged System SOOON

System Overview:
The Slim Frame Multi Sliding Facade is designed to open wide architectural spaces smoothly while maintaining a clean and modern visual identity. The system operates as a multi-sliding facade, providing panoramic views and optimal space utilization.

It features a dual-operation option, functioning as a sliding system for daily use, with the ability to convert the panels into a hinged opening after sliding, allowing the entire opening to be fully cleared when required without compromising architectural appearance or structural performance.

Engineering Configuration:
The system is manufactured using high-quality aluminum profiles with a Slim Frame design and operates with a multi-sliding mechanism supported by a fully top-hung load system to ensure balanced load distribution and stable performance.
The facade consists of three fully movable panels with no fixed elements, allowing maximum flexibility for partial or full opening.
The system is fitted with single glazing, ensuring lightweight operation and clear visibility while maintaining reliable functional performance.
The system allows standard sliding operation, with an optional hinged opening mode where the panels can be pivoted after sliding to fully open the entire facade, providing maximum spatial flexibility.
All loads are carried by integrated upper tracks within the top profile, while a bottom guide wheel is used solely for alignment and smooth guidance without any load-bearing function.

The system offers full flexibility in customizing glass type, number of panels, profile heights, handle positions, and opening direction according to site conditions and client requirements, while maintaining smooth operation and structural stability.

Accessories:
All accessories are manufactured entirely from high-quality aluminum and include a soft-close system, recessed integrated handles, a multi-point locking system, and concealed hinge mechanisms dedicated to the hinged-opening option.
All hardware is fully concealed within the aluminum profiles, with handles finished using electrostatic coating matching the facade color.

Safety and Insulation:
The facade is equipped with rubber gaskets between the glass and aluminum profiles, along with sealing brushes between panels to prevent air, dust, and insect infiltration.
The system ensures safe, stable, and controlled operation in both sliding and hinged modes, suitable for long-term daily use.

Optional Folding Aluminum Mesh System:
The facade can be equipped with an optional folding aluminum mesh system featuring fine ventilation openings, perimeter brush sealing, and a central locking mechanism (open/close), allowing natural ventilation while preventing insects and maintaining privacy without affecting system operation.

Recommended Applications:
Residential villas
High-end commercial projects
Wide architectural facades
Indoor and outdoor spaces

Maintenance and After-Sales Service:
The system features easy maintenance with readily available spare parts, supported by professional technical support and after-sales service backed by Green Line’s experience in large-scale architectural projects. The system includes a paint warranty of up to 25 years only.
